7075 Aluminum – CNC Machining

7075 aluminum is a high-strength aluminum alloy selected for CNC machined components where maximum structural performance and load-bearing capability are required.

Its machining behavior is strongly influenced by high strength and hardness, requiring controlled cutting parameters to maintain accuracy and surface integrity.

At ShvaveyMetal, aluminum 7075 CNC machining strategies are aligned with the material’s mechanical response to support stable and repeatable production results.

Aluminum 7075 is a heat-treatable aluminium alloy with zinc as its primary alloying element, developed for high-strength structural applications.

It is commonly supplied in tempers such as T6 and T651, where strength is prioritized over corrosion resistance and ease of machining.

Mechanical Properties (Typical – 7075-T6)

Property Typical Value Units
Density ~2.81 g/cm³
Yield Strength ~505 MPa
Ultimate Tensile Strength ~570 MPa
Elongation at Break ~11 %
Elastic Modulus ~71 GPa
Hardness (Brinell) ~150 HB

Values may vary depending on temper and applicable standards.

Thermal & Physical Properties

Property Typical Value Units
Thermal Conductivity ~130 W/m·K
Coefficient of Thermal Expansion ~23.5 µm/m·K
Melting Range ~475–635 °C

These characteristics influence heat management and dimensional stability during CNC machining.

Chemical Composition (Representative)

Element Typical Content (%)
Aluminum (Al) Balance
Zinc (Zn) 5.1 – 6.1
Magnesium (Mg) 2.1 – 2.9
Copper (Cu) 1.2 – 2.0
Chromium (Cr) 0.18 – 0.28
Iron + Silicon ≤ 0.5

Composition ranges depend on material standards and supplier specifications.

Aluminum 7075 CNC machining presents greater challenges than 6xxx aluminum alloys due to the material’s high strength.

Key machining characteristics include:

  • Higher cutting forces and increased tool wear
  • Reduced margin for aggressive cutting strategies
  • Stable chip formation under optimized parameters
  • Sensitivity to heat buildup during prolonged machining

With appropriate tooling, fixturing, and process control, CNC machining aluminum 7075 supports tight tolerances and consistent results.

Benefit Description
Very High Strength Suitable for highly loaded structural components
Strength-to-Weight Ratio Enables lightweight yet robust designs
Dimensional Stability Maintains geometry in precision applications
Structural Reliability Performs well under static and dynamic loads

7075 aluminum is commonly used for CNC machined components such as:

  • High-load brackets and fittings
  • Performance-critical machine components
  • Structural frames and supports
  • Precision parts requiring maximum strength

Application suitability depends on loading conditions, geometry, and temper selection.

Temper General Characteristics
T6 Maximum strength, standard condition
T651 Stress-relieved T6 for improved dimensional stability
T73 Reduced strength with improved corrosion resistance

7075-T6 and 7075-T651 are the most common conditions for CNC machining.

When designing CNC machined parts from aluminum 7075, consideration should be given to:

  • Conservative cutting parameters to manage tool wear
  • Rigid fixturing to control vibration
  • Effective coolant application
  • Allowance for reduced corrosion resistance compared to 6xxx alloys
  • Early alignment between design intent and machining strategy is essential for stable production

FAQ

What is the machinability of 7075 aluminum?

7075 machines very well, with a machinability rating comparable to or better than 6061 in the T6 temper. Its higher strength increases cutting forces somewhat, but it produces excellent chip breaking and fine surface finishes. Tool life is generally good, and the main production challenge is distortion rather than cutting difficulty.

How is distortion controlled when machining 7075 aluminum?

Structural parts machined from plate often remove most of the stock volume, releasing residual stress and causing movement. Control comes from stress relieved tempers such as T651 or T7351, balanced material removal from both faces, staged roughing and finishing, and fixturing that constrains without inducing stress. Intermediate stress relief may be used on critical components.

Is 7075 suitable for screw-cutting and turned components?

Yes. 7075 turns well and produces clean, well-formed threads with good surface quality, making it suitable for high-strength turned and screw-machined parts. Its strength allows smaller thread forms to carry higher loads than equivalent 6061 components, which is valuable in weight-critical assemblies.

How does 7075 compare with 6061 for machined parts?

7075 offers roughly double the yield strength of 6061-T6, making it the choice for highly loaded structural components. 6061 has better corrosion resistance, is readily weldable and costs less. 7075 is generally not fusion welded and can be susceptible to stress corrosion cracking in the T6 temper, which the T73 tempers mitigate.

What are machined 7075 aluminum components used for?

Typical applications include high load structural fittings and brackets, tooling, automation and motion components, and precision parts where strength to weight ratio is the governing requirement. It is frequently specified as a lightweight substitute for steel in weight sensitive assemblies.


Why Machine 7075 Aluminum at ShvaveyMetal

ShvaveyMetal applies material-specific CNC machining strategies supported by controlled workflows, inspection, and traceability.

This approach ensures that CNC machined 7075 aluminum components meet defined dimensional, surface, and performance requirements across both prototype and serial production programs.
